Carbon Steel Wire

Name: Carbon Steel Wire
SKU: 0

Tel：+86 17866717031

WhatsApp：+86 17866717031

Email：amy@sdfivestarmetal.com

Get a Free Quote

Product Parameters

Product Introduction

Product Name：Carbon steel wire rod

Type: Low carbon steel wire/ High carbon steel wire

Diameter： 0.15-16.00mm

Material：Q235 SAE1006 1008 1010 1022 Low Carbon Steel /1070 1065 1045 High Carbon Steel Wire

MOQ：1 ton , We can accept sample order.

Product type：Plain round/Twisted

Export packing ：Standard Export Seaworthy Package.Suit for all kinds of transport,or as required

Standard：GB,DIS,JIS , EN

Surface treatment：Custom Made,Black,Polishing,Mirror A/B,Lusterless,Acid Washing,Varnish Paint

Delivery time： 7-10 days after receive the deposit.

Technology: cold drawn, cold rolled, hot rolled.

Main application : making spring,mattress,wire rope, brush, cable

DIN :The customer request

Product specification

Product Name	Carbon steel wire
Material	NVA,NVD, A,A32,, A36, AH32, AH36, B,16MnL, D32, D36, DH32, DH36, EH32, EH36Q195, Q235, Q235B, Q345, 10-50#, 16Mn, 20Mn, 35Mn, 45Mn, 50Mn, 20Mn2, 35Mn2, 45Mn2.15CrMo, 35CrMo, 42CrMo, 20CrMo, 12Cr1MoV, 27SiMn, 60Si2Mn, 20Cr, 40Cr15GrMoG , 10GrMo910 , 12Gr2MoG , 12Gr1MoVG, 1Gr5Mo, 1Gr9Mo , P11, T11 , T91 , T22 , P22 , P5 , P9 , WB36
Standard	GB,DIS,JIS , EN
Diameter	0.16-16mm
Tensile Strength	350-550MPA; 800-1800MPa
Delivery terms	EXW,FOB,CFR,CIF,CNF etc.
Exported Area	USA,UAE,Europe,Asia,Middle East,Africa,South America or other areas.
Lead Time	3-5days if this goods is stock goods ; 10-15 days if this goods will be produced after order
Payment Terms	30% T/T in advance as deposit,70% balance before delivery
Remark	Specific requirement of alloy grade,temper or specification can be discussed at your request

Grade	Rank	Chemical Composition( %)
Grade	Rank	C	Mn	Si	S	P
Q195		0.06~0.12	0.25~0.50	≤0.3	≤0.05	≤0.045
Q215	A	0.09~0.15	0.25~0.55	≤0.3	≤0.05	≤0.045
Q215	B	0.09~0.15	0.25~0.55	≤0.3	≤0.045	≤0.045
Q235	A	0.14~0.22	0.30~0.65	≤0.3	≤0.05	≤0.045
	B	0.12~0.20	0.30~0.70	≤0.3	≤0.045	≤0.045
	C	≤0.18	0.35~0.80	-----	≤0.04	≤0.04
	D	≤0.17	0.35~0.80	-----	≤0.035	≤0.035
Q255	A	0.18~0.28	0.40~0.70	≤0.3	≤0.05	≤0.045
Q255	B	0.18~0.28	0.40~0.70	≤0.3	≤0.045	-----
Q275		0.28~0.38	0.50~0.80	≤0.35	≤0.05	≤0.045

Main Applications:

1. Construction steel bar binding

The largest consumption scenario. Widely used for tying steel bars in buildings, bridges, roads and infrastructure projects across South America, Southeast Asia and the Middle East.

2. Raw material for welded wire mesh

Base material for making common welded mesh, square mesh, strainer mesh; factories purchase carbon wire to self-produce mesh then do surface anti-rust treatment.

3. Daily packaging & cargo bundling

Used for bundling bricks, wood, pipes, cartons and bulk goods in factories, logistics yards and warehouses for fixed packaging.

4. Handicraft & wrought iron processing

Iron art ornaments, metal handicrafts, flower stand frames, daily hardware stamping and forming raw materials.

5. Agricultural tying usage

Bind fruit branches, crop seedlings, greenhouse supports, farm simple enclosure fixing in farmland and orchards.

6. Filter mesh, metal mesh for filter equipment

Internal support skeleton of industrial filter screens, filter tubes and filter equipment.
